◉ Adopts advanced Direct Digital Synthesizer (DDS) waveform generation technology, featuring high frequency stability and good continuity;
◉ High measurement accuracy, suitable for testing current sine half-waves and various similar waveforms with DC components;
◉ Equipped with an embedded intelligent PC monitoring system;
◉ Fully adjustable output voltage: low range 0-150V, high range 0-300V, with a step size of 0.1V;
◉ Output frequency: 45-120Hz (40-500Hz optional), with a step size of 0.1Hz;
◉ Output current limiting function;
◉ Has 3 groups of memory to store commonly used parameters (voltage V, frequency F, current I) for easy recall during use;
◉ Equipped with RS232C communication interface [IEEE488.2 (GPIB) optional], with an instruction execution time of less than 10ms; (communication interface optional);
◉ Protection modes: overvoltage, overcurrent, overload, short circuit, current limiting, etc.;
◉ Provides readings such as RMS voltage, RMS current, active power, frequency, power factor, etc.;
◉ For 100% load removal and loading, the stable response time is within 20ms, with strong overload capacity, and the instantaneous current can withstand 3 times the rated current;
◉ Input and output isolation.
| AS1000 Series Single-Phase Variable Frequency Power Supply | |||||||||||||
| Model | AS1000 | AS1001 | AS1003 | AS1005 | AS1010 | AS1015 | AS1020 | AS1030 | AS1050 | AS1100 | AS150 | ||
| Power capacity | 500 VA | 1 KVA | 3 KVA | 5 KVA | 10 KVA | 15 KVA | 20 KVA | 30 KVA | 50 KVA | 100KVA | 150KVA | ||
| Production method | SPWM | ||||||||||||
| INPUT | Phase | 1φ2 W+ PE Single-phase two-wire + ground wire | 3φ4 W+ PE Three-phase four-wire + ground wire | ||||||||||
| Voltage | 220 V±15 % | 380 V±15 % | |||||||||||
| Frequency | 47 Hz – 63 Hz | ||||||||||||
| OUTPUT | Phase | 1φ2 W+ PE Single-phase two-wire + ground wire | |||||||||||
| Voltage | Low range 0 – 150 VAC / High range 0 – 300 VAC | ||||||||||||
| Frequency | 45-120 Hz( 40 – 500 HZoptional)，0 . 1 Step | ||||||||||||
| Max Current | L= 120 V | 4. 2 A | 8 . 4 A | 25 A | 42 A | 84 A | 125 A | 168 A | 250 A | 420 A | 840 A | 1250 A | |
| H= 240 V | 2 . 1 A | 4 . 2 A | 12 . 5 A | 21 A | 42 A | 62 . 5 A | 84 A | 125 A | 210 A | 420 A | 625 A | ||
| LED Display | Vrms、Arms、Fre 、Wattage 、PFC | ||||||||||||
| Linear Regulation | 0 . 1 % | ||||||||||||
| Load Regulation | 1 % | ||||||||||||
| Harmonic T. H. D | 2%(purely resistive load) | ||||||||||||
| Frequency Regulation | 0 . 01 % | ||||||||||||
| Voltage Resolution | 0 . 1 V | ||||||||||||
| Frequency Resolution | 0 . 1 Hz | ||||||||||||
| Current Resolution | 0 . 0 01 A | 0 .01A | 0 . 1 A | 1 A | |||||||||
| Measurement accuracy | Voltage | 0 . 5 % FS+ 5 dgt | |||||||||||
| Current | 0 . 5 % FS+ 5 dgt | ||||||||||||
| Wattage | 0 . 5 % FS+ 5 dgt | ||||||||||||
| Frequency | 0 . 01 % FS+ 5 dgt | ||||||||||||
| Set accuracy | Voltage | 0.3 % FS | |||||||||||
| Current | 0 . 1 % FS | ||||||||||||
| Storage groups | M 1 ( V_ F_ A )﹑M 2 ( V_ F_ A )﹑M 3 ( V_ F_ A) | ||||||||||||
| Interface | RS 232C【IEEE 488 . 2( GPIB) Optional】 | ||||||||||||
| I-LIM Set | O-Max Current | ||||||||||||
| Protection | Over Current Over Temp Over Load Short Circuit | ||||||||||||
| weight( Kg) | 15 | 20 | 30 | 50 | 80 | 120 | 150 | 200 | 400 | 500 | 600 | ||
| volumeW×H×D( mm) | 430×133×370 | 430×177 ×460 | 430×430 ×450 | 430×765×550 | 550×1280×700 | 800×1680×850 | |||||||
| Environment | -10～45℃ 10 – 90 % RH | ||||||||||||
| AS1000S Series Three-Phase Variable Frequency Power Supply | |||||||||||||||
| Model | AS1006S | AS1010S | AS1015S | AS1020S | AS1030S | AS1045S | AS1060S | AS1100S | AS1150S | AS1300S | AS1450S | AS11000S | |||
| output Capacity | 6KVA | 10KVA | 15KVA | 20KVA | 30KVA | 45KVA | 60KVA | 100KVA | 150KVA | 300KVA | 450KVA | 1000KVA | |||
| Production method | SPWM | ||||||||||||||
| INPUT | Phase | 1φ2W+PE Single-phase two-wire + ground wire | 3φ4W+PE Three-phase four-wire + ground wire | ||||||||||||
| Voltage | 220V±15% | 380V±15% | |||||||||||||
| Frequency | 47Hz-63Hz | ||||||||||||||
| OUTPUT | Phase | 3φ4W+PE Three-phase four-wire + ground wire | |||||||||||||
| Voltage | Low gear 0-150VAC / High gear 0-300VAC | ||||||||||||||
| Frequency | 45.00-120.0Hz(40.00-500.0HzOptional, 10-1000Hz custom-made)，0.1Step | ||||||||||||||
| Max Current | L=120V | 16.8A | 28A | 42A | 56A | 84A | 168A | 280A | 420A | 560A | 840A | 1400A | 2800A | ||
| H=240V | 8.4A | 14A | 21A | 28A | 42A | 84A | 140A | 210A | 280A | 420A | 700A | 1400A | |||
| LED display (Phase A) Display | Vrms、Arms、 Fre、Wattage、 PFC | ||||||||||||||
| Line Regulation | 0.1% | ||||||||||||||
| Load Regulation | 1% | ||||||||||||||
| T.H.D | 2%（Purely resistive load） | ||||||||||||||
| Frequency Accuracy | 0.01% | ||||||||||||||
| Voltage Resolation | 0. 1V | ||||||||||||||
| Frequency Resolation | 0.1Hz | ||||||||||||||
| Current Resolation | 0.01A | 0.1A | 1A | ||||||||||||
| Measurement accuracy | Voltage | 0.5%FS+5dgt | |||||||||||||
| Current | 0.5%FS+5dgt | ||||||||||||||
| Watte | 0.5%FS+5dgt | ||||||||||||||
| Frequency | 0.01%FS+5dgt | ||||||||||||||
| Set precision | Voltage | 1% FS | |||||||||||||
| Current | 0.1% FS | ||||||||||||||
| Memor group | M1(V_F_A)、M2(V_F_A)、M3(V_F_A) | ||||||||||||||
| Interface | RS232/RS485【IEEE488.2（GPIB）optional】 | ||||||||||||||
| I-LIM Set | 0—Max Current | ||||||||||||||
| Protection | Over Current Over Temp Over Load Short Circuit | ||||||||||||||
| Weight（KG） | 75 | 90 | 120 | 150 | 200 | 300 | 500 | 900 | 1200 | 1800 | 2500 | 5000 | |||
| volume W×H×D（mm） | 430×800×700 | 550×1280×700 | 800×1680×850 | 1000×2000×1050 | 1500×2000×1350 | 3000×2000×1050 | |||||||||
| Work Condition | -10～45℃ 10～90%RH | ||||||||||||||
